PAPER TO CAD CONVERSION DRAFTING
TURNAROUND
$/SHEET
4 - 6 Weeks
$200.00
10 Days
$250.00
5 Days
$300.00
3 Days
$400.00
Next Day Service
$700.00
AS BUILTS/REDLINE MARK-UPS SERVICES & SOLAR DESIGN SERVICES
TURNAROUND
$/SHEET
4 - 6 Week
$200.00
10 Business Days
$220.00
5 Business Days
$250.00
3 Business Days
$280.00
Next Day Service
$290.00
Solar Photovoltaic Plans $250.00
– Take engineering roof measurement (provided by you), making sure estimated number of panels will fit on the roof, taking into account Fire Department requirements.
– Detailed Plans designed specifically for YOUR solar installation
– Use the plans to guide you or your contractor in the installation
– Complete package ready to submit to the city for permit approval
– Every Solar Electrical Design is drafted to comply with city codes and NEC regulations.
– Free revisions if required by the city for permit approval
Designs for permitting includes:
Plot Plan – Site
Single Line Drawing
Ampacity & Voltage calculations, and Solar breaker size
Module data sheets
Inverter data sheets
Full Submittal Package
