Our Services
RDG is a professional drafting and conversion service company catering to contractors, architects, engineers, designers, etc. We have made the entire process of drawing conversion simple and tailored to your individual needs.
Our As-built / Redline Markup Service is ideal for creating as-builts based on marked-up hardcopy documents.
We will update your marked-up drawings into your choice of AutoCAD Revit and Architecture as we as Chief Architect. To get started, just mail your “red-line” hardcopy drawings and electronic files to our office or email us the necessary files.
Our updating process of manually hand drafting each sheet is designed to perfectly match the original documents. We never use “scan to vector” applications to convert your drawings, due to the possibility of errors. All sheets are based on the layering contained in the original electronic file.
Note: We must have the original electronic AutoCAD or Revit files before we can update your marked up drawings.
RED INK = Add changes,
BLUE INK = Drafting instructions
*NO STRUCTURAL CHANGES*
I will begin your project after having received 50% of the total fee for the project, and the remaining 50% before receiving final drawings. Any minor corrections will be at no additional cost to you.
Prices may vary based on each client’s proposed scope of work. Please contact us for more information.
Once I have received all the information for your project I will email you a fixed quote with a timeframe.
Deliverables; via email or CD
$5 to write to a CD and shipping charges as applicable.
Business Hours: Mon. – Fri. (Based on a Job to Job, or the client’s deadline)
I do not scan to conversion. I do accurate manual conversions. They are accurate CAD drawings according to plan dimensions.
Home/Site visits on remodel designs.
